Z35 v3

Capacitive touch panel with a backlit 3.5” display, proximity sensor, internal temperature probe, internal humidity sensor and thermostats for two independent areas. It is able to contain up to 56 controls/indicators, distributed in up to 7 pages with a navigation menu. A screensaver with date, time and/or temperature is set when the touch panel is not in use and the menu is shown automatically when the user approaches thanks to the proximity sensor. Its brightness is regulated by the ambient luminosity sensor included. In addition, it incorporates 4 analog-digital inputs that may be configured as binary inputs for sensors and potential-free push buttons, as temperature probe inputs or as motion sensor inputs. It is compatible with KNX Secure. Accessories: temperature probe, motion sensor.

Zennio offers various finishes to suit a wide range of decorative environments, using colour references based on international standards. This table lists the available finishes along with their corresponding reference to facilitate identification and selection.

Colours shown are based on the RAL system, an international norm widely used to define hues with precision.

Finish Name		RAL (colour reference)	YY / XX ref suffix
	Silver	RAL 9006	S / 06
	Anthracite black	RAL 9004	A / 05
	Matt white	RAL 9016	W or MW / 09
	Champagne	RAL 1035	C / 04
	Mocha	RAL 7006	M / 03
